UNIOS

2 types of LED pitch (7.1 or 17.8mm) for profile and cove lighting.

The 5 wattage options, ranging from 2 to 15W/m, utilize the same LED package to ensure consistent CCT.

High efficient LED package achieving up to 185 lm/W.

Direct light luminaire, designed to use monochrome LED lamps, DALI 48Vdc dimmable with searching and addressing function. Ceiling-, wall- or surface-mounted. Consists of a body and supports for installation, to be ordered separately. The body is made of extruded aluminium and includes die-cast aluminium end caps with 50/60 Shore A silicone seals. It is subjected to a multi-step, pretreatment process, in which the main phases are degreasing, fluorozirconation (a protective surface film) and sealing (with a nanostructured silane layer). The following painting stage consists of a primer and a liquid acrylic paint, cured at 150°C, with a high level of weather and UV ray resistance. The top of the optical assembly is closed by a 3 mm thick transparent glass screen, fixed with silicone.

Surface mounted downlight, luminaire body made of aluminium housing with white powder coated finish. Reflector finish available White, Silver and Black Chrome. White finish and honeycomb accessory available upon request.

Ground recessed direct light luminaire designed to use Warm White monochrome LED lamps and a Wall Grazing optic. Extruded aluminium body with die-cast aluminium end caps complete with silicone seals. IP67, IK09 DIMENSION : L1080*W55*H74MM
