LINEALIGHT

SURFACE TRACKLIGHT

INDOOR LIGHTING

81988W85

Single emission projectors for indoor application. The warm white LED light source with a adjustable focus light distribution is composed of 1 arrayled LEDs. The device body is made of die-cast aluminium en ab - 46100 and features a embossed black ral 9005 finish, processed by means of powder coating. The ingress protection degree is IP20; the total weight is of 0.390 kg. The device features protection class II and can be ceiling-mounted. Compliant with the EN 60598-1 standard and its specific provisions.

Specification

Power

15.5W

Color Temperature

3000K

Light Source Type

LED

Lumen Output

478LM

Finishing

BLACK

IP Rating

IP20

Color Rendering

CRI 92

Driver

ON/OFF DRIVER

WE-EF

INGROUND UPLIGHT

OUTDOOR LIGHTING

RGBW Colour Changer. IP67. Class I. IK10+. Stainless steel construction including PCS hardware. Safety glass lens, max. load 5 tonnes. Luminaire can be driven over at low speed. Silicone rubber gasket. Factory-sealed termination chamber with cable gland and 0.5 m of flexible PVC-free cable. Integral EC electronic converter. Advanced thermal management protects LEDs while optimising lumens output. Removable LED boards for upgrading. CAD-optimised optics for superior illumination and glare control. OLC One LED Concept. 20° tiltable and 355° rotatable. LED circuit board with WEEF Colour Boost Technology. DMX Interface. For other control interface options to suit specific project requirements, contact WEEF. Luminaire installation blockout and sealable junction box included in supply

CDN LIGHTING

RECESSED DOWNLIGHT

INDOOR LIGHTING

DALITEK

CONTROL SYSTEM

220VAC single phase power input, 1 channel DALI DIN-Rail control signal output，1 channel switch output，20A/CH, each channel supports 64 DALI address（Support mixed use of DT6 and DT8）
