XAL

LINEAR DOWNLIGHT
INDOOR LIGHTING
UNICO L3 HIGH EFFICIENT_090-7L301C0B31 090-7L3020B

Rectangular recessed multi-downlight made of die-cast aluminium; installation without tools in mounting set due to patented ball catch system; rectangular installation housing; with trim jet black; suitable for ceiling thickness of 2-25 mm; equipped with three flood round light elements; symmetrical light distribution with precise radiation characteristic, beam angle 49°; high quality reflector with micro-faceted, aluminum-vaporised surface; black reflector; UGR ≤ 16

Specification

Power
8.8W
Color Temperature
3000K
Light Source Type
LED
Lumen Output
994LM
Finishing
BLACK TRIM / BLACK REFLECTOR
IP Rating
IP20
Color Rendering
CRI 90
Driver
ON/OFF DRIVER

See more

CDN LIGHTING
RECESSED DOWNLIGHT
INDOOR LIGHTING


LINEALIGHT
TRACKLIGHT
INDOOR LIGHTING

 Double emission systems for indoor application. The super warm white LED light source with a diffused + medium wide flood light distribution is composed of 168 topled LEDs with CCT of 2700 K and a CRI 90; the source luminous flux is 7142 lm, with a 148.8 lm/W nominal luminous efficacy. The device body is made of aluminium and features a white finish, processed by means of coating; the diffuser is made of pmma; the diffuser is made of PC. The ingress protection degree is IP40; the total weight i

BEGA
FOOT LIGHT
OUTDOOR LIGHTING

Luminaire made of aluminium alloy, aluminium and stainless steel BEGA Tricoat® coating technology Colour graphite or silver Safety glass with optical structure Required recessed opening 175 x 175mm Recessed depth 105mm Fixing is achieved by using two adjustable wedge-shaped claws.2 cable entries for through-wiring of mains supply cable ø 7-10.5mm, max. 5G1.5@ Connecting terminal and earth conductor terminal 2.5@ Complies with flicker requirements in accordance with IEEE 1789, DIN IEC/TR 63158, D

SIMES
INGROUND UPLIGHT
OUTDOOR LIGHTING
Die-cast EN AB-44100 aluminium housing (copper free) with high corrosion resistance. Marine grade stainless steel AISI 316L 3 mm thick for RING or aluminium front trim for FLAT. Toughened glass diffuser 12mm thick for MICRORING, 15mm thick for MINIRING, 19mm thick for RING/MEGARING, 10mm thick for MICROFLAT, 12mm thick for MINIFLAT, 15mm thick for FLAT/MEGAFLAT. Stainless steel screws. Luminaire hard wired with single neoprene cable with cable gland. Fast connector IP68 included. Recessing box in polypropylene. Silicone gaskets.
