WEVER & DUCRE

SURFACE MOUNTED DOWNLIGHT
INDOOR LIGHTING
BOX 1.0LED_186164B4_3000K-21°

Squared ceiling surface mounted downlight made from die-cast aluminium; surface Black Matt; powder coated; matt texture; RAL 9011; optional single inner reflector and single inner cover available; with COB (Chip on Board) technology for maximum efficiency; phase-cut dim; light colour 3000 K The ingress protection degree is IP20.

Specification

Power
8W
Color Temperature
3000K
Light Source Type
LED
Lumen Output
710LM
Finishing
BLACK MATT
IP Rating
Color Rendering
CRI >80
Driver
ON/OFF DRIVER

See more

LINEALIGHT
RECESSED DOWNLIGHT
INDOOR LIGHTING
Single emission downlights for indoor application. The warm white LED light source with a spot light distribution is composed of 1 powerled LEDs. The device body is made of aluminium 6026 and features a embossed black ral 9005 finish, processed by means of powder coating; the diffuser is made of uv resistant polycarbonate. The ingress protection degree is IP44; the total weight is of 0.078 kg. The power supply driver is not provided and is to be ordered separately. The power supply cable is included and features a 0.170 m length. The device features protection class III and can be ceiling-mounted, with a 29 mm diameter hole (in plasterboard). Compliant with the EN 60598-1 standard and its specific provisions.
SPARK
RECESSED DOWNLIGHT
INDOOR LIGHTING

Recessed pin-hole downlight made of aluminium housing with white powder coated finish. Black finish available upon request. Luminaire come with 2 different sizes, 6-8W in Ø63mm and 8-15W in Ø90mm.

LIGHTFORMS
SURFACE MOUNTED LIGHT
INDOOR LIGHTING
The MoonBand collection of suspended and surface-mount rings is the larger-form, big brother to our popular MoonRing family of luminaires. MoonBand 40 — the narrowest member of the series — is available in five diameters with three standard outputs plus RGB+ W and offers the choice of direct, indirect or direct/ indirect distribution. Drivers are remoted.
LINEALIGHT
INGROUND UPLIGHT
OUTDOOR LIGHTING

Single emission lines for outdoor application. The super warm white LED light source with a asymmetric wallwasher light distribution is composed of 18 powerled LEDs with CCT of 2700 K and a CRI 80; the source luminous flux is 5076 lm, with a 139.1 lm/W nominal luminous efficacy. The device body is made of aluminium 6060 and features a anodised black finish, processed by means of 15 µm anodizing; the diffuser is made of extra clear glass - tempered with a silk-screening treatment. The ingress protection degree is IP67; the total weight is of 4.8 kg. The total absorbed power is 41 W. The power supply cable is included and features a 0.2 m length. The device features protection class I and can be floor-mounted with an outer casing, code 98726(for concrete or masonry). Compliant with the EN 60598-1 standard and its specific provisions.
