Product Detail
Home Products Detail

Products

WE-EF

INGROUND UPLIGHT
OUTDOOR LIGHTING
ESC330_185-7493

IP67. IK07. Stainless steel inground section. Die-cast hood made from marine-grade aluminium alloy. Construction helps to prevent accumulation of insects, leaves and debris on lens and restricts glare to passers-by. 5CE superior corrosion protection including PCS hardware. Safety glass lens. Silicone rubber gasket. Factory-sealed termination chamber with cable gland and 0.5 m of flexible PVC-free cable. Integral EC electronic converter. Advanced thermal management protects LEDs while optimising lumens output. Removable LED boards for upgrading. CAD-optimised optics for superior illumination and glare control. OLC® One LED Concept. Luminaire installation blockout and sealable junction box included in supply.

Specification

Power
24W
Color Temperature
4000K
Light Source Type
LED
Lumen Output
2531LM
Finishing
GREY
IP Rating
IP67
Color Rendering
CRI 80
Driver
1-10V DRIVER

See more

CUSTOMIZED
GLOBE LIGHT
OUTDOOR LIGHTING


SIMES
INGROUND LINEAR LIGHT
OUTDOOR LIGHTING
Fixing base and recessing box in extruded anodized EN AW-6060 aluminium housing (copper free) with high corrosion resistance. Mechanical resistance IK 10 Maximum load capacity 500 Kg. This luminaire contains built-in LED modules. In case of damage or malfunction please contact the manufacturer to receive additional instructions on how to replace and relative spare parts to order. The LED modules cannot be handled in the luminaire by the end user. This product contains a light source of energy efficiency class: G. LED modules are engineered accordingly to the existing regulations of Lumen Maintenance (LM80) and Technical Memorandum (TM21), where uniformity and quality of the light is 70,000 hours referred to L80 B10 Ta 25 ° C (50,000 hours referable to L80 B10 Ta 40°C). Lifespan of the luminaire min. 50,000 hours at 40°C. Performance Ambient temperature Tq 25°C. Operating ambient temperature range is from -20°C to +50°C. Storage temperature range from -20°C to +60°C.
IGUZZINI
RECESSED DOWNLIGHT
INDOOR LIGHTING
Fixed round mini-recessed luminaire with contact frame. The LED is set back to minimize direct glare. The recessed body is made of machined aluminium and the inside of the ring of thermoplastic available in a range of painted and metallised finishes. PMMA - medium (25°) high resolution optic lens.
LIGMAN
UNDERWATER LIGHT
OUTDOOR LIGHTING

 Stainless steel body in grade 316; One cable gland supplied with 2 m of 2x1.0 sqmm outdoor cable; Durable silicone rubber gasket; Clear toughened glass; Remote driver (included); Remote box IP-rated is not included and is to be ordered separately for constant current (CC) products; Recessing box in PVC is included; Luminaire must be submerged when operational; Maximum depth 2 m.; Outdoor cable needs to be ordered with a spec
