FLOS

RECESSED DOWNLIGHT

OUTDOOR LIGHTING

ECLECTIC 70 FIXED FLAT_05.8016.40

Eclectic Ø70. Non-adjustable Downlight. “Flat” style façade. Necessary installation pre-frames, not included (to be ordered separately). Recessed position of the LED: 55º cut-off angle. IP54 water tightness. Alternative options for lenses, orientation modules and style façades are available as spare parts. The ingress protection degree is IP54.

Specification

Power

10W

Color Temperature

3000K

Light Source Type

LED

Lumen Output

452LM

Finishing

WHITE

IP Rating

IP54

Color Rendering

CRI90

Driver

DALI Driver

MEYER

LINEAR GRAZER

OUTDOOR LIGHTING

Ecoline is a luminaire series for LEDs with wall washer, asymmetrical or wide beam optics. In addition to stand alone luminaires, there is also a modular system with hardly any shadows between the modules. Despite having integral control gear, the cross section of these luminaires is extremely small. This enables them to be used very discreetly in any architectural situation. Ecoline is available with monochrome white LEDs or RGBW LEDs with an integral DMX driver.

LINEALIGHT

RECESSED DOWNLIGHT

INDOOR LIGHTING

Single emission downlights for indoor application. The warm white LED light source is composed of 1 powerled LEDs. The device body is made of die-cast aluminium en ab - 46100 and features a embossed black ral 9005 finish, processed by means of powder coating; the diffuser is made of uv resistant polycarbonate. The ingress protection degree is IP44; the total weight is of 0.250 kg. The power supply driver is not provided and is to be ordered separately. The device features protection class III and can be ceiling-mounted, with a 64 x 64 mm hole (in plasterboard). Compliant with the EN 60598-1 standard and its specific provisions.

LINEALIGHT

PROJECTOR LIGHT

OUTDOOR LIGHTING

Single emission projectors for outdoor application. The warm white LED light source with a medium flood light distribution is composed of 1 arrayled LEDs. The luminaire body is made of aisi 316 steel and features a steel finish, processed by means of electropolishing; the diffuser is made of extra clear glass - tempered with a silk-screening treatment. The ingress protection degree is IP68,IK10.
