WE-EF

BOLLARD

OUTDOOR LIGHTING

114-9790

IP66/IP67. Class I. IK10. Marine-grade, all-aluminium construction. Pole section features galvanised steel reinforcement core. 5CE superior corrosion protection including PCS hardware. RFC™ Reflection Free Contour main lens. Silicone CCG® Controlled Compression Gasket. Luminaire is factory-sealed and does not need to be opened during installation. Integral EC electronic converter. Advanced thermal management protects LEDs while optimising lumens output. CAD-optimised optics for superior illumination and glare control.

Specification

Power

24W

Color Temperature

3000K

Light Source Type

LED

Lumen Output

2835LM

Finishing

ANTHRACITE GREY

IP Rating

IP66

Color Rendering

CRI 80

Driver

ON/OFF DRIVER

SIMES

INGROUND LINEAR LIGHT

OUTDOOR LIGHTING

Fixing base and recessing box in extruded anodized EN AW-6060 aluminium housing (copper free) with high corrosion resistance. Mechanical resistance IK 10 Maximum load capacity 500 Kg. This luminaire contains built-in LED modules. In case of damage or malfunction please contact the manufacturer to receive additional instructions on how to replace and relative spare parts to order. The LED modules cannot be handled in the luminaire by the end user. This product contains a light source of energy efficiency class: G. LED modules are engineered accordingly to the existing regulations of Lumen Maintenance (LM80) and Technical Memorandum (TM21), where uniformity and quality of the light is 70,000 hours referred to L80 B10 Ta 25 ° C (50,000 hours referable to L80 B10 Ta 40°C). Lifespan of the luminaire min. 50,000 hours at 40°C. Performance Ambient temperature Tq 25°C. Operating ambient temperature range is from -20°C to +50°C. Storage temperature range from -20°C to +60°C.

BEGA

BOLLARD

OUTDOOR LIGHTING

Bollard with rotationally symmetrical lightdistribution. For lighting surfaces and paths from low mounting height. For interior and exterior application. The luminaire consists of aluminium profiles, cast aluminium and stainless steel.IP65,IK06.

LIGHTFORMS

SURFACE MOUNTED LIGHT

INDOOR LIGHTING

Micro-S is a clean and compact luminaire that provides direct illumination. The slim channel provides for a minimalist-looking aesthetic. Driver is REMOTE.
