LIGMAN

WALL LIGHT

INDOOR LIGHTING

NYB-30012-O-W30

Luminaire made of die-cast aluminium end-caps and extruded aluminium profile with powder coating. Single cable entry.Stainless steel fasteners in grade 316. PMMA diffuser with Opal (UGR <19) and micro prismatic (UGR <13) options for better glare control. Up and down light distribution options. Passive thermal management, integral control gear. Wireless control available through Bluetooth connection. Daylight and occupancy sensor options. Emergency module (1 or 3 hours) is available upon request with 3 options (BASIC, SELF-TEST, PRODALI). IP20.

Specification

Power

19W

Color Temperature

3000K

Light Source Type

LED

Lumen Output

1735LM

Finishing

ALUMINIUM

IP Rating

IP20

Color Rendering

CRI80

Driver

ON/OFF DRIVER

LIGHTFORMS

RECESSED DOWNLIGHT

INDOOR LIGHTING

This ceiling recessed downlight is highly functional, with a 360° rotate and 45° tilt. This allows for more adjustment at higher angles needed to illuminate a space at higher level. High lumen output capability and available in various finishes and colour temperatures, this light fitting is perfect for retail, workplace and hospitality lighting schemes.

XAL

LINEAR DOWNLIGHT

INDOOR LIGHTING

Rectangular recessed multi-downlight made of die-cast aluminium; installation without tools in mounting set due to patented ball catch system; rectangular installation housing; with trim jet black; suitable for ceiling thickness of 2-25 mm; equipped with three wide flood square light elements; symmetrical light distribution with precise radiation characteristic, beam angle 71°; high quality reflector with micro-faceted, aluminum-vaporised surface; chrome reflector; passive cooling of the LEDs through improved heat sink geometry; light colour 3000 K; binning initial MacAdam ≤ 3 SDCM; CRI ≥ 90; min. 90% of luminous flux after 50000 operating hours; energyefficient high power LEDs with very good colour rendering; degree of protection IP20; PC2; incl. converter, non dimmable; through wiring connection box, 3-pole or 5-pole, available as an accessory; accessories are listed separately; light source not replaceable; control gear replaceable by an authorized professional; clank-free

LINEALIGHT

LED NEON TUBE

OUTDOOR LIGHTING

Single emission led strip for indoor or outdoor application. The warm white LED light source with a spot light distribution is composed of 1 topled LEDs with CCT of 3000 K and a CRI 85; the source luminous flux is 2300 lm, with a 121.1 lm/W nominal luminous efficacy. The device body is made of pu and features a white finish. The ingress protection degree is IP67; The power supply driver is not provided and is to be ordered separately. The total absorbed power is 19 W. The power supply cable is included and features a 1(M)x0.25m + 1(F)x0.25 m lengtH. The device features protection class III and can be wall lights, ceiling or floor-mounted

LINEALIGHT

ADJUSTABLE DOWNLIGHT

INDOOR LIGHTING

Single emission downlights for indoor application. The dynamic white LED light source with a spot light distribution is composed of 25 powerleds LEDs. Luminaire body and mounting frame is made of die-cast aluminium with a embossed black RAL 9005 finish, processed by means of powder coating. The ingress protection degree is IP20
