LINEALIGHT

In-ground luminaire with single-sided light for recessed mounting in compacted surfaces, paths and places. An orientation and indication luminaire also for marking danger points. Drive-over luminaire for vehicles with pneumatic tyres. Luminaire must not be used for installation in road lanes, where the fixture is exposed to a horizontal strain due to braking, acceleration and change of direction. Luminaires and installation housings made of highly corrosion-resistant aluminium. Ring made of glass fibre reinforced synthetic material Borosilicate glass and reflector surface made of pure aluminium. Optical silicone lens. IP67, IK10

DIMENSION : Ø240*H230MM

"Copper Free" Aluminium die cast housing in EN AB-44100 with high resistance against corrosion. Stone wash surface treatment prior to painting process. A4 grade Stainless Steel screws with 2,5-3% molybdenum content which increases the resistance against corrosion. Pre treated Silicone Gaskets. Painting Process : 3 Step Process: 1) Surface treatment with BONDERITE. A heavy metal free chemical surface treatment containing ceramic nano particles giving a cohesive, inorganic and highly dense protective coating. 2) PRE POLYMERIZATION a process of introducing an epoxy primer with excellent characteristics to the paint which also offers very high resistance to oxidation due to its Zinc content. 3) POLYMERIZATION a process with the application of polyester powder with high resistance against UV rays and harsh weather conditions. Resistance test protection for Marine applications for 1200h. Mechanical resistance IK 09 Maximum load capacity 1000 Kg. This luminaire contains built-in LED modules. In case of damage or malfunction please contact the manufacturer to receive additional instructions on how to replace and relative spare parts to order. The LED modules cannot be handled in the luminaire by the end user. This product contains a light source of energy efficiency class: E. LED modules are engineered accordingly to the existing regulations of Lumen Maintenance (LM80) and Technical Memorandum (TM21), where uniformity and quality of the light is 70,000 hours referred to L80 B10 Ta 25 ° C (50,000 hours referable to L80 B10 Ta 40°C). Lifespan of the luminaire min. 50,000 hours at 40°C. Performance Ambient temperature Tq 25°C. Operating ambient temperature range is from -20°C to +50°C. Storage temperature range from -20°C to +60°C.

Ceiling and wall luminaire with free-radiating and uniform light distribution. By arraying single luminaires in line light bands of different length can be arranged. Linear luminaire illumination in interior and exterior application. Luminaire made of aluminium alloy, aluminium and stainless steel. Safety glass and white silicone gasket. IP65, IK05

DIMENSION : L1010*W105*H60

Lightplane Linear Wall Washer Recessed Trim is a large recessed, wall washing fixture with trim. The fixture is available with with multiple lamping options including LED, Tunable White LED, RGB colour changing LED.
