LUMASCAPE

In-ground luminaire made of aluminium alloy body. Locking flange in AISI 316L stainless steel. A4 Stainless steel screws. Subjected to galvanic anodizing treatment divided into distinct phases: mechanical satin finishing, surface degreasing, anodic oxidation and final sealing. Installation of the recessed housing is cast concrete with a 20-30cm gravel soakaway. IP67, IK10

The Ethernet Processor Module is an ultra compactDIN rail mounted unit with connections for anEthernet gateway, an M-BUS network and an RS-232port.Using Ethernet you can connect separate M-BUSnetworks together via a dedicated TCP/IP backbone or the shared building IT network.RS-232 and Ethernet facilitate integration with AV and building control systems.Web based programming and app control are available when connected to a network.

Recessed adjustable oval-hole downlight made of aluminium housing with white powder coated finish. Black finish and Honeycomb accessory available upon request.

TA5 + LED Module/ M4P3-0301513A-TA5-BB

Round recessed mounted downlight made of die-cast aluminium with black powder-coating finish (RAL 9005) and black reflector; LED 13W; measurement Ø85mm; ceiling cutout of Ø75mm with a narrow mounting trim; rotation 355°and pivot max. 30°; CCT 3000K with a System Luminous Flux of 1000lm high color rendering at an index of CRI97; SDCM: 2; after a lifetime of 50000h L80B10 min. 80% of the luminous flux with energy efficient BRIDGELUX LED Chips; 5 years warrant
