VARIOLED FLEX WHITE HYDRA HD10 W825 1019 IP67

IP67 flexible 24 V linear LED strip up to 7.5 m in length. Polyurethane encapsulation offering a premium water proof sealing, UV resistance, chemical stability against urban gazes and protection against abrasion. White lower casing for higher efficiency (better light extraction). Delivered with 200 mm IP67 mini connectors on both ends. Constant Voltage LED strip with 62.5 mm and a small LED pitch of 8.93 mm the first choice for outdoor applications with a direct top view or indirect lighting with low construction depths – with perfectly homogeneous light. Assembled using state of the art automated Reel to Reel (R2R) production process supporting LED Linear™ Tj Away thin flexible circuit board technology.

Specification

Power

10W/M

Color Temperature

3300K

Light Source Type

LED

Lumen Output

890LM/M

Finishing

WHITE

IP Rating

IP67

Color Rendering

CRI 90

Driver

ON/OFF DRIVER

IGUZZINI

RECESSED LINEAR LIGHT

OUTDOOR LIGHTING

Direct light luminaire, designed to use monochrome LED lamps, DALI 220÷240Vac dimmable with searching and addressing function and transparent glass cover. Ground-, wall- and ceilingrecessed. Option of installation in continuous lines of up to a max length of 10.5m only for ground-recessed installation. Made up of a body, end caps, an outer casing and caps to be ordered separately. Extruded aluminium body, with die-cast aluminium end caps complete with silicone seals.

LINEALIGHT

WALLWASHER

OUTDOOR LIGHTING

Single emission lines for outdoor application. The warm white LED light source with a elliptic light distribution is composed of 9 powerled LEDs. The device body is made of aluminium 6060 and features a anodised aluminum finish, processed by means of 20 µm anodizing; the diffuser is made of extra clear glass - tempered with a silk-screening treatment. The ingress protection degree is IP67; the total weight is of 5.5 kg. The total absorbed power is 51 W. The power supply cable is included and features a 0.17 m length. The device features protection class I and can be floor-mounted with an outer casing, code 99771 (for concrete or masonry). Compliant with the EN 60598-1 standard and its specific provisions.

IGUZZINI

SURFACE LINEAR LIGHT

OUTDOOR LIGHTING

Compact direct light luminaire using monochrome LEDs, DMX512-RDM dimmable (48Vdc), for ceiling, wall, or surface mounting. Made of extruded aluminium with die-cast end caps and silicone seals, treated for high weather and UV resistance. Features a 3mm transparent glass screen, integrated Warm White multi-LED plate, and DMX512-RDM driver (ballast sold separately). Includes PG11 connectors for pass-through wiring and methacrylate lens for flood optics. Complies with EN 60598-1 standards.
