Products
LINEALIGHT
UP/DOWN WALL LIGHT
OUTDOOR LIGHTING
81191W30
Single emission uplights for outdoor application. The warm white LED light source with a flood light distribution is composed of 1 arrayled LEDs. The device body is made of die-cast aluminium en ab - 46100 and features a black finish, processed by means of open pore anodizing + powder coating; the diffuser is made of extra clear glass - tempered with a silk-screening treatment. The ingress protection degree is IP68; the total weight is of 0.5 kg. The power supply cable is included and features a 1 m length. The device features protection class III and can be floor-mounted with an outer casing, code 99856 (for concrete or masonry). Compliant with the EN 60598-1 standard and its specific provisions.
Specification
- Power
- 9W
- Color Temperature
- 3000K
- Light Source Type
- LED
- Lumen Output
- 717LM
- Finishing
- BLACK
- IP Rating
- IP68
- Color Rendering
- CRI 80
- Driver
- ON/OFF DRIVER
