LINEALIGHT

WALLWASHER

OUTDOOR LIGHTING

81689W90

Single emission lines for outdoor application. The warm white LED light source with a extra wide flood light distribution is composed of 12 powerled LEDs. The device body is made of aluminium 6060 and features a anodised aluminum finish, processed by means of 20 µm anodizing; the diffuser is made of extra clear glass - tempered with a silk-screening treatment. The ingress protection degree is IP68; the total weight is of 2.010 kg. The power supply cable is included and features a 0.250 m length. The device features protection class II and can be floor-mounted with an outer casing, code 99764 (for concrete or masonry). Compliant with the EN 60598-1 standard and its specific provisions.

Specification

Power

19.1W

Color Temperature

3000K

Light Source Type

LED

Lumen Output

1589LM

Finishing

ANODISED ALUMINUM

IP Rating

IP68

Color Rendering

CRI 80

Driver

ON/OFF DRIVER

LINEALIGHT

WALLWASHER

OUTDOOR LIGHTING

Single emission lines for outdoor application. The warm white LED light source with a medium flood light distribution is composed of 9 powerled LEDs. The device body is made of aluminium 6060 and features a anodised black finish, processed by means of 15 µm anodizing; the diffuser is made of extra clear glass - tempered with a silk-screening treatment. The ingress protection degree is IP67; the total weight is of 2.8 kg. The power supply cable is included and features a 0.2 m length. The device features protection class I and can be floor-mounted with an outer casing, code 98672 (for concrete or masonry). Compliant with the EN 60598-1 standard and its specific provisions.

SPARK

ADJUSTABLE DOWNLIGHT

INDOOR LIGHTING

Mini adjustable recessed downlight Ø35mm, cut-out Ø32mm. Various beam angles from 8, 15, 24, 36, 45 and 60°. Color finishing White available upon request. IP20

TRAXON

WALLWASHER

OUTDOOR LIGHTING

The ProPoint Linear 2.0 HO RGBW is an AC Line powered luminaire in a slim profile. The ProPoint Linear 2.0 HO RGBW is available in 8W (SO) or 12W (HO) per foot output, 4 beam options, standard & custom finishes which can meet the needs for most projects. The daisy chain topology is augmented with a separate Data Injector allowing single cable feed combining data and power to fixtures. IP66

DIMENSION : 300mm x 58mm x 90mm
