LINEALIGHT

WALLWASHER
OUTDOOR LIGHTING
96197W25
Single emission lines for outdoor application. The warm white LED light source with a elliptical light distribution is composed of 12 powerled LEDs. The device body is made of uv resistant polycarbonate and features a transparent finish; the diffuser is made of uv resistant polycarbonate. The ingress protection degree is IP67; the total weight is of 0.89 kg. The power supply cable is included and features a 0.25 m length. The device features protection class II and can be wall lights, ceiling or floor-mounted with an outer casing, code 98844 (for concrete or masonry). Compliant with the EN 60598-1 standard and its specific provisions.

Specification

Power
19.4W
Color Temperature
3000K
Light Source Type
LED
Lumen Output
1710LM
Finishing
TRANSPARENT
IP Rating
IP67
Color Rendering
CRI 80
Driver
ON/OFF DRIVER

See more

XAL
RECESSED LINEAR LIGHT
OUTDOOR LIGHTING

Surface white powder coated luminaire housing made of extruded aluminium profile; recessed light with wrap around edge; suitable for ceiling thickness of 8- 20 mm. Luminaire profile (end caps come pre-assembled) can be pre-mounted; remaining lamp components mounted without tools; closed light insert made of PMMA, consisting of converter unit and circuit board unit; light inset with screwedon, thus maintenance-friendly, transparent end cap in PMMA. IP54

SPARK
SPIKE LIGHT
OUTDOOR LIGHTING

Outdoor Spike light made of die cast aluminium housing. Beam angle available in 15, 30, 45 and 60° IP65.

DIEMNSION : Ø65MM

CDN LIGHTING
RECESSED DOWNLIGHT
INDOOR LIGHTING


XAL
RECESSED DOWNLIGHT
INDOOR LIGHTING
Rectangular recessed multi-downlight made of die-cast aluminium; installation without tools in mounting set due to patented ball catch system; rectangular installation housing; with trim jet black; suitable for ceiling thickness of 2-25 mm; equipped with two medium round light elements; symmetrical light distribution with precise radiation characteristic, beam angle 33°; high quality reflector with micro-faceted, aluminum-vaporised surface; black reflector; UGR ≤ 10; VDU compatible workplace luminaire according to DIN EN 12464-1; luminance above 65° ≤ 3000 cd/m²; passive cooling of the LEDs through improved heat sink geometry; light colour 3000 K; binning initial MacAdam ≤ 3 SDCM; CRI ≥ 90; min. 90% of luminous flux after 50000 operating hours; energyefficient high power LEDs with very good colour rendering; degree of protection IP20; PC2; incl. converter, non dimmable; through wiring connection box, 3-pole or 5-pole, available as an accessory; accessories are listed separately; light source not replaceable; control gear replaceable by an authorized professional; clank-free;
