Product Detail | Bloxlimited

LINEALIGHT

WALLWASHER

OUTDOOR LIGHTING

84214W00

Single emission lines for outdoor application. The warm white LED light source with a diffused light distribution is composed of 90 topled LEDs. The device body is made of uv resistant polycarbonate and features a black finish; the diffuser is made of uv resistant polycarbonate. The ingress protection degree is IP67; the total weight is of 0.40 kg. The power supply driver is not provided and is to be ordered separately. The power supply cable is included and features a 0.25 m length. The device features protection class III and can be wall lights or floormounted. Compliant with the EN 60598-1 standard and its specific provisions.

Specification

Power

Color Temperature

3000K

Light Source Type

LED

Lumen Output

270LM

Finishing

BLACK

IP Rating

IP67

Color Rendering

CRI 80

Driver

ON/OFF DRIVER

CASAMBI

CONTROL SYSTEM

S4i NANO 2dbi BLE antenna, 400m line of sign when used in pair. Also available with 5dbi, 8dbi, 12dbi options.

MARSET

WALL LIGHT

OUTDOOR LIGHTING

Product type: Wall / Ceiling

Light source: LED COB 230 VAC 8W 2700K CRI90 571lm

Luminaire: 230 VAC TRIAC 8,47W 89lm

Weight: Net 0,8 kg – Gross 1,2 kg

Package: 29 x 30,5 x 12,5 cm - 1,2 kg – VOL - 0,01 m3

LED included

LINEALIGHT

SURFACE TRACKLIGHT

INDOOR LIGHTING

Single emission projectors for indoor application. The warm white LED light source with a spot light distribution is composed of 1 arrayled LEDs. The device body is made of die-cast aluminium en ab - 46100 and features a embossed black ral 9005 finish, processed by means of powder coating. The ingress protection degree is IP20; the total weight is of 0.390 kg. The device features protection class II and can be ceiling-mounted. Compliant with the EN 60598-1 standard and its specific provisions.
