LINEALIGHT

Housing made of corrosion‑resistant die‑cast aluminum AlSi12, double polyester powder coated by high‑quality and UV‑stabilized coating process, Colour: black ral 7021, all exterior parts are stainless steel, tempered safety glass flush with frame, anti‑reflective coating from 1 side, design element with dark screen print, for loads up to max. 2000 kg (according to IEC / EN 60598‑2‑13), silicon gasket, cover frame and closure with 2 stainless steel screws, with polypropylene recess housing, cable gland: M20 (stainless steel), connecting terminal: 3 pole, highly efficient optics made of transparent thermoplastic for precise lighting tasks , with 1 m cable H07RN‑F3G1, integral potted driver (AC/DC), CRI > 80, max 2 SDCM, service life L90/B10 > 50.000 h, luminous flux: 1054 lm, wattage: 15 W, delivered lumens 70 lm/W, protection type IP67, protection class I, impact resistance IK10, dimensions (L×H×W): 648 × 99 × 84 mm, weight 3.6 kg. The modular luminaire design makes the replacement of components possible. The product meets the demands of the applicable EU guidelines and product safety regulations and bears the CE mark. Customized solutions and modifications are possible: Special ral, db or ncs colours as polyester powder coat, luminaires in 2700 K and other colour temperatures and versions for high ambient temperature.

The Traxon ProPoint Kontour Rhythm is a slim, DC 24v powered flexible tube that is omni-bendable on both the horizontal and vertical axes. Its high flexibility is perfect for any curved surface or freeform installation, as well as straight highlighting applications for low-profile, high impact illumination. ProPoint Kontour Rhythm is available in customizable lengths and cable feed locations. Controllable in 76mm / 3” segments, it can be used to distinguish facades, walls and architectural borders with a concentrated, even radiance, or can be used to create a dynamic river of light flowing along ceilings and walls. This product is intended for use in high-quality colored light applications
