Product Detail | Bloxlimited

LINEALIGHT

WALLWASHER

OUTDOOR LIGHTING

81606W27

Single emission lines for outdoor application. The warm white LED light source with a asymmetric wallwasher light distribution is composed of 27 powerled LEDs. The device body is made of aluminium 6060 and features a anodised aluminum finish, processed by means of 20 µm anodizing; the diffuser is made of extra clear glass - tempered with a silk-screening treatment. The ingress protection degree is IP67; the total weight is of 7 kg. The power supply cable is included and features a 0.2 m length. The device features protection class I and can be wall lights or floormounted with an outer casing, code 99760 (for concrete or masonry). Compliant with the EN 60598-1 standard and its specific provisions.

Specification

Power

61.4W

Color Temperature

3000K

Light Source Type

LED

Lumen Output

5161LM

Finishing

ANODISED ALUMINUM

IP Rating

IP67

Color Rendering

CRI 80

Driver

ON/OFF DRIVER

FORMALIGHTING

WALLWASHER

INDOOR LIGHTING

EVO track mounted Zero Compasso wallwasher, available in three sizes (Ø42, Ø66 and Ø100mm) versatile aiming angle tiltable vertically 0°-90° and rotatable horizontally 360°. Perfect for museums and galleries applications. Wallwashing with high uniformity can be used to illuminate artwork and sculptures. Vertical uniformity creates a wide and distinguished spatial impression by brightening the entire height of the wall.

LINEALIGHT

RECESSED DOWNLIGHT

INDOOR LIGHTING

Single emission downlights for indoor application. The warm white LED light source with a medium flood light distribution is composed of 1 arrayled LEDs. The device body is made of die-cast aluminium en ab - 46100 and features a black finish, processed by means of powder coating; the diffuser is made of uv resistant polycarbonate. The ingress protection degree is IP44; the total weight is of 0.511 kg. The power supply driver is not provided and is to be ordered separately. The power supply cable is included and features a 0.300 m length. The device features protection class III and can be ceiling-mounted, with a 95 mm diameter hole (in plasterboard). Compliant with the EN 60598-1 standard and its specific provisions.

LIGMAN

UNDERWATER LIGHT

OUTDOOR LIGHTING

BOH-60013-M-8030-ND-00: BORNHOLM 2 - BOH-60013 - 4 LED - 8 W - 17° - 3000K CRI80 - On/Off - Stainless Steel (Without remote driver - With recessing box - Constant voltage (CV) 24 V)

ข้อมูลทางเทคนิค - ดวงโคมสแตนเลส; สายไฟเดี่ยว; มี 1 PG พร้อมสายไฟภายนอก ขนาด 2x1.0ตร.มม. ยาว 2 เมตร; ตัวยึดสแตนเลสเกรด 316; ปะเก็นยางซิลิโคนที่ทนทาน; กระจกนิรภัยแบบใส; สีผลิตภัณฑ์: สเตนเลสสตีล; IP68; IK07; อุณหภูมิในการทำงาน: -20 °C to 40 °C; วัสดุ: สเตนเลสสตีล. ออปติคอล - รูปแบบการกระจายแสง M; 17°; ลูเมน (lm): 795 lm

LINEALIGHT

RECESSED DOWNLIGHT

INDOOR LIGHTING

Single emission downlights for indoor application. The super warm LED light source with a wide flood light distribution is composed of 1 powerled LEDs with CCT of 2700 K and a CRI 80; the source luminous flux is 136 lm, with a 136.0 lm/W nominal luminous efficacy. The device body is made of brass and features a chrome finish, processed by means of electroplating. The ingress protection degree is IP44.
