Preview Real Lighting Products in Blox 3D Simulator Using IES Files
Products
LINEALIGHT
RECESSED DOWNLIGHT
INDOOR LIGHTING
86614Z15
Single emission downlights for indoor application. The RGB LED light source with a flood light distribution is composed of 3 powerled LEDs. The device body is made of brass and features a chrome finish, processed by means of electroplating. The ingress protection degree is IP44; the total weight is of 0.079 kg. The power supply driver is not provided and is to be ordered separately. The power supply cable is included and features a 0.12 m length. The device features protection class III and can be wall lights or ceilingmounted, with a 29 mm diameter hole (in plasterboard) with an outer casing, code 84901 (for concrete or masonry). Compliant with the EN 60598-1 standard and its specific provisions.
Specification
- Power
- 2.1W
- Color Temperature
- RGB
- Light Source Type
- LED
- Lumen Output
- 114LM
- Finishing
- CHROME
- IP Rating
- IP44
- Color Rendering
- CRI 80
- Driver
- ON/OFF DRIVER
