LINEALIGHT

RECESSED DOWNLIGHT

INDOOR LIGHTING

80035W45

Single emission downlights for indoor application. The warm white LED light source with a medium wide flood light distribution is composed of 1 arrayled LEDs. The device body is made of die-cast aluminium en ab - 46100 and features a embossed white ral 9003 finish, processed by means of powder coating; the diffuser is made of uv resistant polycarbonate. The ingress protection degree is IP44; the total weight is of 0.511 kg. The power supply driver is not provided and is to be ordered separately. The power supply cable is included and features a 0.300 m length. The device features protection class III and can be ceiling-mounted, with a 75 mm diameter hole (in plasterboard). Compliant with the EN 60598-1 standard and its specific provisions.

Specification

Power

15W

Color Temperature

3000K

Light Source Type

LED

Lumen Output

789LM

Finishing

WHITE

IP Rating

IP44

Color Rendering

CRI 92

Driver

ON/OFF DRIVER

BEGA

FOOT LIGHT

OUTDOOR LIGHTING

Luminaire made of aluminium alloy, aluminium and stainless steel BEGA Tricoat® coating technology Colour graphite or silver Safety glass with optical structure Required recessed opening 175 x 175mm Recessed depth 105mm Fixing is achieved by using two adjustable wedge-shaped claws.2 cable entries for through-wiring of mains supply cable ø 7-10.5mm, max. 5G1.5@ Connecting terminal and earth conductor terminal 2.5@ Complies with flicker requirements in accordance with IEEE 1789, DIN IEC/TR 63158, D

BEGA

INGROUND UPLIGHT

OUTDOOR LIGHTING

Recessed inground uplight luminaire ,made of stainless steel. Housing made of aluminium profile, powder-coated with 2 entries for connection cable up to ø 12mm.Drive-over luminaire from vehicles with pneumatic tyres. Dust-tight and water pressure tight.. IP67,IK09. DIMENSION:(W)400 x(HEIGHT)100x(D)55mm.

XAL

LINEAR DOWNLIGHT

INDOOR LIGHTING

Rectangular recessed multi-downlight made of die-cast aluminium; installation without tools in mounting set due to patented ball catch system; rectangular installation housing; with trim jet black; suitable for ceiling thickness of 2-25 mm; equipped with four flood round light elements; symmetrical light distribution with precise radiation characteristic, beam angle 49°; high quality reflector with micro-faceted, aluminum-vaporised surface; black reflector; UGR ≤ 16; VDU compatible workplace luminaire according to DIN EN 12464-1; luminance above 65° ≤ 3000 cd/m²; passive cooling of the LEDs through improved heat sink geometry; light colour 3000 K; binning initial MacAdam ≤ 3 SDCM; CRI ≥ 90; min. 90% of luminous flux after 50000 operating hours; energy-efficient high power LEDs with very good colour rendering; degree of protection IP20; PC2; incl. converter, non dimmable; through wiring connection box, 3-pole or 5-pole, available as an accessory; accessories are listed separately; light source not replaceable; control gear replaceable by an authorized professional; clank-free

XAL

RECESSED LINEAR LIGHT

INDOOR LIGHTING

Low profile recessed channel, height 13 mm; suitable for rimless installation in 12.5mm plasterboard ceilings; specially designed trim with grooves for better adhesion of smoothing compound; suitable for wall or ceiling mounting; for continuous lighting systems; surface white powder coated; easy mountng without need to cut the substructure; fall-safe light inset made of extruded aluminium profile, can be inserted in the canal without tools by magnetic holders; with asymmetric light distribution.
