LINEALIGHT

Rotatability 350°, pivotability 30° · Series compatible with each other, uniform cutout diameter · Weight: 0.67 grams · 2 powder-coated color options · RAL colors on request · Dimmability depends on the ballast · Direct light colors: optionally 2700K, 3000K, 3500K or 4000K. · CRI > 90 · MacAdam: 3 · IP protection type IP65 · Height: 122 mm · Diameter: 108 mm

Round recessed trimless downlight (Easy Installation) made of die-cast aluminium with white powder-coating finish (RAL 9016) and white reflector; 0-10V Dim Driver; System Power 21W; measurements Ø96mm x 131mm; ceiling cutout of Ø108mm with a trimless mounting; ceiling thickness 1-25mm; rotation 355° and pivot max. 30°; CCT 2700K with a System luminous flux of 1600lm; high color rendering at an index of CRI90; after a lifetime of 50000h L80B10 min.

The rimless luminaire PI² WHITELINE from the familiy PI² consists of white painted steel. The luminaire with direct illumination and corresponds IP20 at protection class 1. The ballast is integrated and allows for an operation with 220-240V (50/60Hz). PI² WHITELINE (# 11242) is dimmable via BUS. The rimless luminaire PI² WHITELINE from the familiy PI² consists of white painted steel. The luminaire with direct illumination and corresponds IP20 at protection class 1. The ballast is integrated and allows for an operation with 220-240V (50/60Hz). PI² WHITELINE (# 11242) is dimmable via BUS.

Luminaire made of aluminium alloy, aluminium and stainless steel. Clear synthetic cover with optical structure. Reflector made of pure anodised aluminium. Mounting plate with 3 fixing holes ø 6.5 mm. Angle 120° · Pitch circle ø 122 mm. 2 cable entries for through-wiring of mains supply cable ø 7-10,5 mm, max. 5 G 1.5@ Connecting terminal 2.5@ with plug connection. Earth conductor connection. LED power supply unit 220-240 V x 0/50-60 Hz. DC 176-264 V, During DC operation the LED power is reduced to 50 % DALI controllable. A basic isolation exists between power cable and control line. Safety class I. Protection class IP 65. Dust-tight and protection against water jets. Impact strength IK10. Protection against mechanical. impacts < 20 joule. c – Conformity mark.
