Product Detail | Bloxlimited

LINEALIGHT

SURFACE TRACKLIGHT

INDOOR LIGHTING

82409W15

Single emission projectors for indoor application. The warm white LED light source with a spot light distribution is composed of 1 arrayled LEDs. The device body is made of die-cast aluminium en ab - 46100 and features a embossed black ral 9005 finish, processed by means of powder coating. The ingress protection degree is IP20; the total weight is of 0.390 kg. The device features protection class II and can be ceiling-mounted. Compliant with the EN 60598-1 standard and its specific provisions.

Specification

Power

15.5W

Color Temperature

3000K

Light Source Type

LED

Lumen Output

861LM

Finishing

BLACK

IP Rating

IP20

Color Rendering

CRI 98

Driver

ON/OFF DRIVER

SIMES

INGROUND UPLIGHT

OUTDOOR LIGHTING

Sophisticatd optical systems able to considerably reduce glare thanks to the retracted position of the LED. Optical reflector in black polycarbonate combined with transparent methacrylate lenses (Versions with LED). The lathed anodized reflector is composed of HI-GRADE 99,98% pure anodized aluminium with a bright polish finish (Version with COB). Toughened acid-etched glass 8mm thick. Lamp fixed position. LOR --

SPARK

ZOOMABLE DOWNLIGHT

INDOOR LIGHTING

Recessed adjustable Zoomable downlight come with snoot, luminaire body made of aluminium housing with white powder coated finish. Black finish available upon request.

LINEALIGHT

CEILING LIGHT

INDOOR LIGHTING

Single emission downlights for indoor application. The warm white LED light source with a medium wide flood light distribution is composed of 6 powerled LEDs with CCT of 3000 K and a CRI 90; the source luminous flux is 1074 lm, with a 89.5 lm/W nominal luminous efficacy. The device body is made of plaster and features a white finish; the diffuser is made of ABS. The ingress protection degree is IP20; the total weight is of 0.690 kg. The power supply driver is not provided and is to be ordered separately. The total absorbed power is 12 W. The power supply cable is included and features a 0.170 m length. The device features protection class III and can be ceiling-mounted, with a 270 x 90 mm hole (in plasterboard). Compliant with the EN 60598-1 standard and its specific provisions.

DELTALIGHT

RECESSED MAGNETIC TRACK LINEAR

INDOOR LIGHTING

Light modules can easily be positioned and repositioned, thanks to the magnetic connection between module and profile. This allows for an easy adaptation between light and room setting.Magnetic modules to be used with the SPLITLINE and SHIFTLINE profiles.Apart from personal dimming preferences, the light within the magnetic profiles can also be controlled by sensors, based on daylight or presence detection.
