SPARK

Housing made of corrosion‑resistant die‑cast aluminum AlSi12, double polyester powder coated by high‑quality and UV‑stabilized coating process, Colour: black ral 7021, all exterior parts are stainless steel, tempered safety glass flush with frame, anti‑reflective coating from 1 side, design element with dark screen print, for loads up to max. 2000 kg (according to IEC / EN 60598‑2‑13), silicon gasket, cover frame and closure with 2 stainless steel screws, with polypropylene recess housing, cable gland: M20 (stainless steel), connecting terminal: 3 pole, highly efficient optics made of transparent thermoplastic for precise lighting tasks , with 1 m cable H07RN‑F3G1, integral potted driver (AC/DC), CRI > 80, max 2 SDCM, service life L90/B10 > 50.000 h, Beam angle (fwhm): 12° / 108°, luminous flux: 1059 lm, wattage: 15 W, delivered lumens 71 lm/W, protection type IP67, protection class I, impact resistance IK10, dimensions (L×H×W): 648 × 99 × 84 mm, weight 3.6 kg. The modular luminaire design makes the replacement of components possible. The product meets the demands of the applicable EU guidelines and product safety regulations and bears the CE mark. Customized solutions and modifications are possible: Special ral, db or ncs colours as polyester powder coat, luminaires in 2700 K and other colour temperatures and versions for high ambient temperature.

The pendant luminaire SIGN DIVA KORONA from the familiy SIGN consists of aluminum. With 3 powder coated options 15625 colour combinations can be achieved. SIGN DIVA KORONA enhances the architecture with the KORONA EFFECT. The ballast is integrated and allows for an operation with 220-240V (50/60Hz). SIGN DIVA KORONA (# 410-3932) is dimmable via BUS. The luminaire with direct illumination and corresponds to protection class SK1 at IP20.

Suspension / Ceiling mount direct + indirect linear light emission. Recessed with trim or trimless version. Dimmable and non dimmable in two CCT 3000K and 4000K versions.

DIMENSION : L1480*W45*H85
