SPARK

The new Cyclones are our best-ever outdoor enclosures, offering unparalleled protection for large format video projectors between 20-45k lumens, in any climate type. Cyclone enclosures are projector-specific and may be produced for you for any projector in Landscape, Portrait and Ultra Short Throw formats. Each Cyclone model has been thoroughly tested and approved with its designated projector before being released for production. Featuring lightweight aluminum welded construction, Cyclone is an ideal choice for any outdoor projection project. Its powerful AC fan provides efficient cooling, while its salt fog filtering and positive pressure option provides ultimate projector protection.

All Cyclones come with four M12 threaded sockets — one at each corner — top and bottom. Larger models have additional threaded sockets midway along their length for additional security. Stainless steel bolts are provided for attachment to any suitable support structure.

Non-shielded wall luminaire with mouth-blown opal glass for a soft and uniform light distribution. Wall luminaire whose elongated design makes it particularly suitable for mounting on pillars, columns and for the front surface of walls, as well as for local cavities or profiles. The luminaire can be installed horizontally or vertically. Luminaire made of aluminium alloy, aluminium and stainless steel. IP65,IK03.

Single emission downlights for indoor application. The warm white LED light source is composed of 1 arrayled LEDs. The device body is made of PC, processed by means of coating. The ingress protection degree is IP20; the total weight is of 1.5 kg. The power supply driver is not provided and is to be ordered separately. The power supply cable is included and features a 0.30 m length. The device features protection class III and can be ceiling-mounted, with a 180 mm diameter hole (in plasterboard). Compliant with the EN 60598-1 standard and its specific provisions.

Pivot 1.7 code: CP17020FKA-1/projector for outdoor applications/surface mounted (ceiling, wall, ground, spike, strap)

Power consumption: 7W/Power supply: 24Vdc/Lumen output at source: 657 lm (3000K, 7W, CRI 80)/Delivered lumen output: 463 lm (3000K, 34°, 7W, CRI 80)/1 high-intensity power LED, 3-step MacAdam, 50 000h L90 B10 (Ta 25°C)/LED colour: 2700K/Optics: 54°: optical system consisting of a deep-set, high-efficiency TIR lens/CRI Colour Rendering Index: 80/Operating temperature: -20°C — +45°C/Glow wire test: 960°/Photobiological safety: photobiological safety: risk group 1 according to EN 62471:2006/Appliance class: class III/Weight: 400 g/Dimensions: Ø40x75 mm/Energy efficiency class: F (light source) in accordance with EU 2019/2015
