XAL

RECESSED SPOTLIGHT
INDOOR LIGHTING
MOVE IN 45_063-8121518M 063-8822118 002-90724

Round spotlight element in aluminium; surface black powder coated; installation without tools in mounting set due to patented ball catch system; recessed light with wrap around edge; suitable for ceiling thickness of 2-25 mm; spotlight element height adjustable without tools: flush with the ceiling, or extended 25 mm or 35 mm; passive cooling of the LEDs through improved heat sink geometry; with COB (Chip on Board) technology for maximum efficiency; no appearance of multiple shadows

Specification

Power
15.7W
Color Temperature
3000K
Light Source Type
LED
Lumen Output
1380LM
Finishing
BLACK TRIM / BLACK REFLECTOR
IP Rating
IP20
Color Rendering
CRI90
Driver
ON/OFF DRIVER

See more

MEYER
FLOODLIGHT
OUTDOOR LIGHTING

Housing made of corrosion‑resistant die‑cast aluminum AlSi12, polyester powder coated by high‑quality and UV‑stabilized coating process, Colour: black ral 7021, all exterior parts are stainless steel, tempered safety glass, anti‑reflective coating from 1 side, dark screenprint, silicon gasket, closure with 2 stainless steel screws, mounting bracket: 1 elongated hole Ø 7 mm, spacing 18 mm, 1 centre hole Ø 8.5 mm, tilt range: 180°, cable gland: M16, connecting terminal: 3 pole, precise PMMA optics, integral driver (AC/DC), CRI > 80, max 2 SDCM, service life L90/B10 > 50.000 h, Beam angle (fwhm): 27°, luminous flux: 510 lm, wattage: 10 W, delivered lumens 51 lm/W, protection type IP67, protection class I, impact resistance IK08, windage area 0,012 m², dimensions: Ø 123 mm, width 87 mm, weight 1.8 kg. The modular luminaire design makes the replacement of components possible. The product meets the demands of the applicable EU guidelines and product safety regulations and bears the CE and ENEC marks. Customized solutions and modifications are possible: Special ral, db or ncs colours as polyester powder coat, luminaires in 2700 K and other colour temperatures and versions for high ambient temperature.

ROLEDS
RECESSED DOWNLIGHT
INDOOR LIGHTING


LUCE & LIGHT
UNDERWATER LIGHT
OUTDOOR LIGHTING


KOIZUMI
DIM TO WARM DOWNLIGHT
INDOOR LIGHTING
SUNSER SERIES recessed downlight 125mm recessed hole made of die cast aluminium frame, aluminium cone, acrylic or transparent matte panel. Realizes low color temperature changes similar to incandescent bulb. Color temperature can be simultaneously changed when dimmed. Realizes light colour changes for elegant and relaxing spaces. DIM TO WARM 3000K - 2000K
