MEYER

INGROUND UPLIGHT

OUTDOOR LIGHTING

8 663 016 059

Housing of corrosion‑resistant die‑cast aluminum AlSi12, double polyester powder coated by high‑quality and UV‑stabilized coating process, Colour: black ral 7021, all exterior parts are stainless steel, tempered safety glass flush with frame, anti‑reflective coating from 1 side, for loads up to max. 5000 kg (according to IEC / EN 60598‑2‑13), silicon gasket, cover frame and closure with 6 stainless steel screws, cable gland: M20, connecting terminal: 3 pole, highly efficient anodized rotationally symmetrical reflector, lockable, tilt range: 0‑20°, lockable, with Heatslide mechanism for optimal heat dissipation, 0,8 m cable H07RN‑F3G1, integral driver (AC), CRI > 80, 3 SCDM, service life L80/B20 > 50.000 h, Beam angle (fwhm): 42°, luminous flux: 1551 lm, wattage: 19 W, delivered lumens 82 lm/W, protection type IP68, protection class I, impact resistance IK10, dimensions: Ø 220 mm, width 152 mm, weight 3.9 kg. The modular luminaire design makes the replacement of components possible. The product meets the demands of the applicable EU guidelines and product safety regulations and bears the CE mark.

Specification

Power

19W

Color Temperature

3000K

Light Source Type

LED

Lumen Output

1551LM

Finishing

DIE-CAST ALUMINUM

IP Rating

IP68

Color Rendering

CRI>80

Driver

ON/OFF DRIVER

DALITEK

CONTROL SYSTEM

12VDC power input 10 keys programmable control panel, each button is internally illuminated, with free customization of engraved keycaps, stainless steel surface, RS485 communication interface.

LINEALIGHT

WALLWASHER

OUTDOOR LIGHTING

Single emission lines for outdoor application. The warm white LED light source with a medium wide flood light distribution is composed of 12 powerled LEDs. The device body is made of uv resistant polycarbonate and features a transparent finish; the diffuser is made of uv resistant polycarbonate. The ingress protection degree is IP67; the total weight is of 0.39 kg. The power supply cable is included and features a 0.25 m length. The device features protection class II and can be wall lights, ceiling or floor-mounted with an outer casing, code 98843 (for concrete or masonry). Compliant with the EN 60598-1 standard and its specific provisions.

XAL

ADJUSTABLE DOWNLIGHT

INDOOR LIGHTING

Square ceiling mounted spotlight made of aluminium; surface jet black powder coated; Inner colour lacquered in jet black; 20° tiltable; luminaire housing can be attached to mounting plate without tools by interlock; passive cooling of the LEDs through improved heat sink geometry; with COB (Chip on Board) technology for maximum efficiency; no appearance of multiple shadows; light colour 3500 K; ≤ 2 SDCM (initial MacAdam); CRI ≥ 90; min. 90% of luminous flux after 100000 operating hours

PROLICHT

RECESSED DOWNLIGHT

INDOOR LIGHTING

The INVADER Deep recessed spotlight conveys the impression, as if the customizeable Korona Cone would radiate itself, through the use of perfectly matched, high-precision reflector technology. The Korona Cones of these spotlights can be configured in one of the 25 PROLICHT colors and thus allow especially individual lighting concepts without affecting the light color. An optimized heat sink enables a very high lumen package despite a diameter of only 150 mm. Low insertion is an advantage in low
