SIMES

SURFACE MOUNTED DOWNLIGHT
INDOOR LIGHTING
S.3817W.24

Down-light luminaire. IP rating IP 65. Aluminium die cast housing in EN AB-47100 (low copper content) and extruded EN AW-6060 with high resistance against corrosion. Stone wash surface treatment prior to painting process. Steel screws treated with an advanced anticorrosive coating. Silicone Gaskets. Extra-resistant Painting Process.Sophisticatd optical systems able to considerably reduce glare thanks to the retracted position of the LED. The lathed anodized reflector is composed of 99,98%.

Specification

Power
8.8W
Color Temperature
3000K
Light Source Type
LED
Lumen Output
452lm
Finishing
Anthracite grey
IP Rating
IP65
Color Rendering
CRI 80
Driver
ON/OFF DRIVER

See more
