CDN LIGHTING

Round recessed ceiling downlight made of die-cast aluminium with black powder-coating finish (RAL 9005) and black reflector; 1-10V Dim Driver; LED 8.5W; measurement Ø78mm; ceiling cutout of Ø68mm with a narrow mounting trim; luminaire's weight is approximately 260g; CCT 2700K with an LED Output of 470lm; high color rendering at an index of CRI90; after a lifetime of 50000h min. 80% of the luminous flux with energy efficient CITIZEN LED Chips; 5 years warranty; narrow beam characteristic with 10° beam angle; lighting perfectly suitable for reading, writing as well as computer and control work according to DIN EN 12464-1 (UGR<19); degree of housing protection according to DIN EN 60529 (IP20)

Single emission projectors for indoor application. The warm white LED light source with a flood light distribution is composed of 1 arrayled LEDs. The device body is made of die-cast aluminium en ab - 46100 and features a embossed black ral 9005 finish, processed by means of powder coating. The ingress protection degree is IP20; the total weight is of 0.390 kg. The device features protection class II and can be ceiling-mounted. Compliant with the EN 60598-1 standard and its specific provisions.

Surface-mounted downlight housing are made of crrosion-resistant cast aluminium. No-Risen surface treatment. Double powder-coated and tamper-proof screw. Screw-fastened cover frame with safety glass, IP65.

Single emission uplights for outdoor application. The super warm white LED light source with a flood light distribution is composed of 1 arrayled LEDs. The device body is made of aisi 316l steel and features a steel finish; the diffuser is made of extra clear glass with a silk-screening treatment. The ingress protection degree is IP68; The power supply driver is not provided and is to be ordered separately. The total absorbed power is 3 W. The power supply cable is included and features a 1 m length. The device features protection class III and can be floor-mounted with an outer casing, code 84935(for concrete or masonry). Compliant with the EN 60598-1 standard and its specific provisions.
