CDN LIGHTING

SURFACE MOUNTED DOWNLIGHT
INDOOR LIGHTING
HS9102C G3 24W36D


Specification

Power
24W
Color Temperature
3000K
Light Source Type
LED
Lumen Output
1926LM
Finishing
ALUMINUM
IP Rating
IP20
Color Rendering
CRI>95
Driver

See more

LIGMAN
INGROUND UPLIGHT
OUTDOOR LIGHTING

Die-cast aluminium housing. Pre-treated before powder coating ensuring high corrosion resistance. 6 mm thick front ring in grade 316 stainless steel or aluminium. Single cable entry, through wiring upon request. Stainless steel fasteners in grade 304 with zinc flake coating (ZFC). Durable silicone rubber gasket. High-efficiency PMMA lens. Clear or frosted toughened glass. Integral control gear for HA-60036, HA-60037, HA-60049, HA-60050, HA-60196, HA-60197, HA-60209, HA-60215, HA-60295, HA-60296, HA-60305, HA-60306. Remote driver, remote box IP-rated and recessing box is included for HA-60385, HA-60386, HA-60395, HA-60396. Recessing box in high-density polyethylene is included. Suitable for walk-over with a maximum load of 200 kg

LINEALIGHT
CEILING LIGHT
INDOOR LIGHTING
Single emission ceiling lights for indoor application. The warm white LED light source with a diffused light distribution is composed of 161 topled LEDs. The device body is made of aluminium 6060 and features a embossed black ral 9005 finish, processed by means of powder coating; the diffuser is made of uv resistant polycarbonate. The ingress protection degree is IP40; the total weight is of 4.2 kg. The power supply driver is not provided and is to be ordered separately. The device features protection class III and can be wall lights or ceilingmounted. Compliant with the EN 60598-1 standard and its specific provisions.
FORMALIGHTING
CEILING LIGHT
OUTDOOR LIGHTING
Round ceiling luminaire with trim, light body and ring in cast aluminium. Central housing in aluminium extrusion, with toughened safety glass, weatherproof durable silicone gasket and external screws made of stainless steel. Front cover is designed to avoid accumulation of dust and water. Electrical installation includes double cable entry.
ELR
ADJUSTABLE DOWNLIGHT
INDOOR LIGHTING
Recessed round downlight compatible with 35 and 50 series LED modules. Various color temperature from 2700K to 5000K, TuneWHITE and Warm Dim etc. Up to 50,000 hours L80 lamp life with LM80 tested. LED chip packages. Beam pattern options 10, 20, 35, 60. Lumen from 310lm to 1600lm depending on LED module. 77mm cutout, Pinhole aperture 24mm. ATePS Automated Thermal Protection System. ComfyEYE, reduced flicker percentage. Interchangeable LED module system. Optional linear spread lens, IP54 seal, colour, light effect filters and honeycomb anti-glare louvre
