IGUZZINI

24 V, IP67 protected and IK10 certified, linear LED luminaire for indoor and outdoor in-ground installation. Suitable for installation into roads and parking lots according to EN 60598-2-13. To be walked on and traversed by vehicles with air filled tires (including trucks used for delivery). Polyurethane encapsulation offering a premium water proof sealing (values), UV resistance (no coloration or increase of absorption) chemical stability against urban gazes and protection against abrasion. Stainless Steel V4A housing delivered with male/female IP67 connectors. Available either with an opal top layer or transluscent with an internal 10° and 30° lenses for wall grazing. Light source assembled using state of the art automated Reel-to-Reel (R2R) production process supporting LED Linear™ Tj Away thin flexible circuit board technology.

RANGE OF MOTION

HORIZONTAL -180-175° VERTICAL 0-30°

SIZE & WEIGHT

FRAME : DIA 163 / H : 177 / MOUNTING DEPTH : 172 / HOLE DIAMETER 150MM / WEIGHT 1.8KG

Silicone Neon Strip adopts bi-color/ tri-color co-extrusion process, featured baby-skin feel in touch and uniform & natural light in function. It shows great resistance to saline solutions, acid & alkali, corrosive gases, fire and UV. The series include Outline Neon for delicate micro-scene outlining, Magic Neon for innovative styling and Architecture Neon for facade and under-water lighting. The ingress protection degree is IP65,IK06.

Pendant LED luminaire with direct beam made of high-quality extruded aluminium profile; white powder-coating finish; luminaire incl. white canopy (110mm x 65mm x 36mm) with transparent feeder cable as well as cable hangers ; ON-OFF Driver is integrated into the luminaire housing; System Power (Total power consumption) 16W – Low Power; Dimensions of the profile channel (LxWxH): 1271mm x 50mm x 80.5mm.diffusor made of Polymethylmethacrylate clear with microprismatic plate. (UGR<19)
