CDN LIGHTING

Outdoor submerged underwater luminaire come with natural white LED light source with a elliptic m. flood (30°÷39°) x (41°÷60°) light distribution. Luminaire body is made of AISI 316L steel and features a steel finish; the diffuser is made of extra clear glass - tempered with a silk-screening treatment. The ingress protection degree IP68 and IK10

Direct light luminaire, designed to use monochrome LED lamps, DALI 48Vdc dimmable with searching and addressing function and transparent glass cover. Ground-, wall- and ceiling-recessed. Option of installation in continuous lines of up to a max length of 10.5m only for ground-recessed installation. Made up of a body, end caps, an outer casing and caps to be ordered separately. Extruded aluminium body, with die-cast aluminium end caps complete with silicone seals. The ingress prtection degree is IP66,IK10.

Controllable recessed adj downlight come in zoomable beam narrow 10° - 36° OR 15° - 60° beam. Color temperate available 2700K, 3000K, 3500K, 4000K, Tunable 2700K-6000K control via 0-10V, DALI or DMX512 system. 5% - 100% brightness change. Pan 0-355°, Tilt 35°. CRI 90, IP20

DIMENSION : Ø215*H186MM

Outdoor Spotlight housing made of corrosion‑resistant die‑cast aluminum AlSi12, polyester powder coated by high‑quality and UV‑stabilized coating process. Exterior parts are stainless steel, 2 tempered safety glasses: waterproof space for optical film and honeycomb louvres, dark screen print, silicon gasket, closure with 2 stainless steel screws and mounting bracket. IP65 IK08
