TRAXON

LED modular system for recessed No Trim installation, including LED luminaires, aluminum installation profile and diffusers. Drivers included in lighting modules for 220-240V connection to mains or to other lighting modules. DIMENSION : L1125*W35*H120MM

The Traxon Linear Go Maxi DC is a DC line powered exterior luminaire used to distinguish facades, walls, and architectural landmarks with a powerful, even color wash effect. Linear Go’s high-value design features efficient electrical and optical systems, making it ideal for budget-conscious projects. This product is intended for use in high-quality colored light applications. The ingress protection degree is IP66,IK07. DIMENSION:(LxWxH) (320mm x 61mm x 123mm).

Inground walk over fitting. Recessing depth 125 mm. IP rating IP 65 IP67.Body made of BRAL, an aluminium bronze alloy with exceptional resistance in outdoor environments, is combined with black extruded aluminium components, specially anodized to prevent the formation of galvanic currents responsible for oxidation processes. Suitable for applications in C5 environments with high humidity and/or marine exposure (according to UNI EN ISO 9223:2012).Recessing box in polypropylene.

Aluminium die cast housing in EN AB-47100 (low copper content) with high resistance against corrosion. Stone wash surface treatment prior to painting process. A4 grade Stainless Steel screws with 2,5-3% molybdenum content which increases the resistance against corrosion. Silicone gaskets. Painting Process : 3 Step Process. 1) Surface treatment with BONDERITE. A heavy metal free chemical surface treatment containing ceramic nano particles giving a cohesive, inorganic and highly dense protective coating. 2) PRE POLYMERIZATION a process of introducing an epoxy primer with excellent characteristics to the paint which also offers very high resistance to oxidation due to its Zinc content. 3) POLYMERIZATION a process with the application of polyester powder with high resistance against UV rays and harsh weather conditions. Resistance test protection for Marine applications for 1200h. Mechanical resistance IK 06.
