IGUZZINI

SURFACE LINEAR LIGHT
OUTDOOR LIGHTING
LINEALUCE_UF40

Direct light linear luminaire with Warm White multi-LED circuit. Made of extruded aluminum with die-cast end caps, silicone seals, UV- and weather-resistant acrylic coating, and a 5 mm glass screen. Mountable on ceiling, wall, ground, or pendant systems (accessories sold separately). Features pass-through wiring with IP68 connectors, Opti Beam Lens with Wall Grazing Wide Flood optic, and stainless steel screws. Control cards (DMX/DALI) and power supply to be ordered separately.

Specification

Power
19.1W/1.5M
Color Temperature
3000K
Light Source Type
LED
Lumen Output
1315LM/1.5M
Finishing
GREY
IP Rating
IP66
Color Rendering
>80
Driver
0-10V DRIVER

See more

LINEALIGHT
INGROUND UPLIGHT
OUTDOOR LIGHTING

Single emission uplights for outdoor application. The warm white LED light source with a flood light distribution is composed of 1 powerled LEDs with CCT of 3000 K and a CRI 80; the source luminous flux is 490 lm, with a 122.5 lm/W nominal luminous efficacy. The device body is made of die-cast aluminium en ab - 46100 and features a black finish, processed by means of open pore anodizing + powder coating; the diffuser is made of extra clear glass - tempered. The ingress protection degree is IP68.

IGUZZINI
POLE LIGHT
OUTDOOR LIGHTING

Outdoor luminaire with down light symmetrical optic, designed to use LED lamps. Consists of a pole and an optical assembly. Diecast aluminium optical assembly. Internal diffuser in milky, textured polycarbonate to create a high level of light beam uniformity; external diffuser and external screen made of UV-stabilised, transparent polycarbonate. Pole made of hot galvanised steel with powder paint coating and a customised fitting for connecting the optical assembly. Pole with 186x46 mm door. The luminaire technical characteristics conform to EN60598-1 standards and particular requirements.

XAL
WALLWASHER
INDOOR LIGHTING

Round recessed spotlight in die-cast aluminium housing, 360° rotatable. Installation without tools in mounting set due to patented ball catch system. Suitable for ceiling thickness of 2-25 mm; passive cooling of the LEDs through improved heat sink geometry; no multiple shadows. IP20

LINEALIGHT
RECESSED DOWNLIGHT
INDOOR LIGHTING
Single emission downlights for indoor application. The warm white LED light source with a medium flood light distribution is composed of 1 arrayled LEDs. The device body is made of PC, processed by means of coating. The ingress protection degree is IP20; the total weight is of 1.9 kg. The power supply driver is not provided and is to be ordered separately. The power supply cable is included and features a 0.3 m length. The device features protection class III and can be ceiling-mounted, with a 236 mm diameter hole (in plasterboard). Compliant with the EN 60598-1 standard and its specific provisions.
