FORMALIGHTING

RECESSED DOWNLIGHT
INDOOR LIGHTING
M570BL23_90FS28DC10

Square recessed motorized luminaire with retractable light head. Mounting trim and light head are made of cast aluminium, recessed light housing made of painted metal. Moto-Palla In&Out is available in 3 different light head diameters: 66mm, 100mm and 130mm. The luminaire includes brackets for trim installation on ceiling thickness max. 25 mm or trimless installation on ceiling thickness max. 30 mm. Two remote controlled DC motors drive the movements of the fixtures. The fixtures are rotatable horizontally 350° and, tiltable vertically in two directions (0°-10° In, 0°-90° Out). The movements of the fixture, as well as the intensity and the colour tuning of the light, are controlled via CASAMBI™ application.

Specification

Power
30.5W
Color Temperature
FULL SPECTRUM SUNLIGHT
Light Source Type
LED
Lumen Output
710.98LM
Finishing
BLACK
IP Rating
IP20
Color Rendering
CRI 90
Driver
CASAMBI

See more

FLOS
ADJUSTABLE DOWNLIGHT
INDOOR LIGHTING
Eclectic Ø90. Adjustable Downlight (40º tilt, 360º rotation). “Cone” style façade. Necessary installation pre-frames, not included (to be ordered separately). Recessed position of the LED: 41º cut-off angle. IP20 water tightness (for IP54, please ask the dedicated accessory). Alternative options for lenses, orientation modules and style façades are available as spare parts. The ingress protection degree is IP20.
NEKO
ADJUSTABLE DOWNLIGHT
INDOOR LIGHTING

LED Module for NEKO CLUB trim made of die-cast aluminium; black powdercoating finish (RAL 9005); 0-10V Dim Driver; System Power 21W; measurement Ø50mm; luminaires height 76mm; CCT 3000K with a System Luminous Flux of 1600lm; high color rendering at an index of CRI97

LIGHTFORMS
SURFACE MOUNTED LIGHT
INDOOR LIGHTING
Round Lightplane 2 is a compact and streamlined cylindrical luminaire that features integral drivers along with a high-impact satin diffuser lens. The fixture is available with several LED lamping options including multiple outputs and CCTs, tunable white and colour-changing RGB+White. Available in suspended or wall scone (contact factory) models.
WE-EF
BOLLARD
OUTDOOR LIGHTING
IP66. Class I. IK10. Marine-grade, all-aluminium construction. Pole section features anodised aluminium core. 5CE superior corrosion protection including PCS hardware. Polycarbonate main lens, UV-stabilised. Silicone CCG® Controlled Compression Gasket. Luminaire is factory-sealed and does not need to be opened during installation. Integral EC electronic converter. Advanced thermal management protects LEDs while optimising lumens output. CAD-optimised optics for superior illumination and glare control. For 2200 K version available on request.
