M570BL23_90FS19DC10

Square recessed motorized luminaire with retractable light head. Mounting trim and light head are made of cast aluminium, recessed light housing made of painted metal. Moto-Palla In&Out is available in 3 different light head diameters: 66mm, 100mm and 130mm. The luminaire includes brackets for trim installation on ceiling thickness max. 25 mm or trimless installation on ceiling thickness max. 30 mm. Two remote controlled DC motors drive the movements of the fixtures. The fixtures are rotatable horizontally 350° and, tiltable vertically in two directions (0°-10° In, 0°-90° Out). The movements of the fixture, as well as the intensity and the colour tuning of the light, are controlled via CASAMBI™ application.

Specification

Power
30.5W
Color Temperature
FULL SPECTRUM SUNLIGHT
Light Source Type
LED
Lumen Output
710.98LM
Finishing
BLACK
IP Rating
IP20
Color Rendering
CRI 90
Driver
CASAMBI

See more

LUTRON
CONTROL SYSTEM
CONTROL SYSTEM

The Energi Savr Node (ESN) family is a group ofmodular products for the control of lighting loads andmotor loads. PRO LED+ Phase Adaptive Power Modules can beused in a QS Standalone system with an iOS EnergiSavr Application, a Quantum system, myRoom Plussystem*, or an Athena system.• Includes QS link for seamless integration of lightsand controls.

WE-EF
SURFACE MOUNTED LIGHT
OUTDOOR LIGHTING
Marine-grade, die-cast aluminium alloy. 5CE superior corrosion protection including PCS hardware. Safety glass lens. Silicone rubber gasket. Luminaire is factory-sealed and does not need to be opened during installation. Integral EC electronic converter. Advanced thermal management protects LEDs while optimising lumens output. CAD-optimised optics for superior illumination and glare control. OLC® One LED Concept. Two cable entries. Luminaire can be mounted for up or down lighting. Optional 2200 K version up to max. 1050mA available. To be specified at time of ordering.
SIMES
FLOODLIGHT
OUTDOOR LIGHTING

MOVIT is a new extraordinary LED projector for ground or wall installation. It can be used as direct or indirect light and it’s also available with arm. MOVIT has elegant proportions and a smaller visual impact than traditional projectors, easy to install and available with asymmetric and symmetric reflector. It covers a wide range of applications and gives to all designers a high flexibility of use.

FORMALIGHTING
SURFACE MOUNTED LIGHT
INDOOR LIGHTING
The new Canali edge is a revolutionary edge-less lighting system featuring easy and clean installation, eliminating wired connections and gearboxes in the cove. Canali Edge profile features easy-to-clip on adjustable spotlights, together with a dedicated channel for linear cove lights fixed by magnets, all in extruded aluminum. The Integrated 3 phase track system with DALI bus enables full DALI control on both linear and track spots. Small and powerful in-track integrated drivers make it very easy to move and reposition the spotlights and the linear lights.
