LINEALIGHT

Installation Recessed installation in suspended ceilings. Unventilated or ventilated ceilings.

For installation in suspended ceilings with visible T-bars, VTB (24 mm) or one-piece suspended

ceilings.

Connection For permanent connection with 230 V; built-in LED ballast in luminaire. Single

and Start luminaires in systems are equipped with 2.5 m connection cable 5 x 0.75 mm².

System units are equipped with a change-over cable (5 x 1.5 mm²) and a quick-connector

between the luminaire units. Use Con

Outdoor double emission wall lights come with a diffused light distribution composed of 21 top led LEDs. Luminaire body is made of aluminium and features a text white RAL 9003 finish, processed by means of coating; the diffuser is made of glass. IP65, IK06

DIMENSION : Ø126*H107

Single emission wall lights for outdoor application. The warm white LED light source with a asymmetric wallwasher light distribution is composed of 1 powerled LEDs . The luminaire body is made of stainless steel and features a steel finish, processed by means of brushing. The ingress protection degree is IP65, IK10.

Round luminaire for ceiling-mounted installation with option of recessed or pendant installation via an accessory to be ordered separately. Direct emission designed to use warm white 3000K LED lamps. The optical assembly consists of an extruded painted aluminium frame, a satin finish methacrylate diffuser screen for general light emission and a sheet metal rear closing base. The driver is housed in the upper part of the product.
