IGUZZINI

Round recessed spotlight in die-cast aluminium; 1 lamp; surface traffic white; installation without tools in mounting set due to patented ball catch system; round installation housing; with trim jet black; suitable for ceiling thickness of 2-25 mm; passive cooling of the LEDs through improved heat sink geometry; with COB (Chip on Board) technology for maximum efficiency; no appearance of multiple shadows; light colour 3500 K; ≤ 2 SDCM (initial MacAdam); CRI ≥ 90; min. 80% of luminous flux after

IP69. IK10+. Stainless steel construction including PCS hardware. Safety glass lens; max. load 5 tonnes. Luminaire can be driven over at low speed. Silicone rubber gasket. Factory-sealed termination chamber complete with cable gland and 0.5 m of flexible PVC free cable. Integral EC electronic converter. Advanced thermal management protects LEDs while optimising lumens output. Removable LED boards for upgrading. CAD-optimised optics for superior illumination and glare control. OLC One LED Concept. Luminaire installation blockout and sealable junction box included in supply.

Double emission pendant luminaires for indoor application. The warm white LED light source with a diffused light distribution is composed of 192 topled LEDs. The luminaire body is made of aluminium and features a black finish, processed by means of coating The device body is made of aluminium and features a brushed gold finish; the diffuser is made of pmma; the mounting frame is made of iron, with a black finish, processed by means of coating. The ingress protection degree is IP20

Miniaturised round swivel luminaire complete with LED profiler projector in warm white colour tone (2700K). Version compatible with Blade R diam 125mm (12LED) complete with device for coupling it to the luminaire and DALI control gear. Technical body for LED lamp made of die-cast zamak; high definition reflector. The aluminium optical assembly includes a sophisticated telecentric optic system consisting of four anti-reflection treated glass lenses. Black anodised aluminium locknut for manual focusing. The innovative optic system, combined with the option of manual adjustment provides sharp and well-defined wall illumination with no halo effects or soft edges.
