WEVER & DUCRE

Direct light luminaire, designed to use Warm White monochrome LED lamps, and a Wall Grazing optic. Ground-, wall- and ceilingrecessed. Consists of a body and outer casing for installation, to be ordered separately. Extruded aluminium body, with die-cast aluminium end caps complete with silicone seals. The painting process includes a multi-step, pre-treatment process, in which the main phases are degreasing, fluorozirconation (a protective surface film) and sealing (with a nano-structured silane layer). The following painting stage consists of a primer and a liquid acrylic paint, cured at 150°C, with a high level of weather and UV ray resistance. Lower PPS (polyphenylene sulfide) box for control gear. The top of the optical assembly is closed by a 8mm thick transparent glass screen, fixed with silicone. Complete with multi-LED plate in Warm White with 24V dc electronic circuit (ballast to be ordered separately). 24V intelligent driver that ensures light flow emission is constant even when the input voltage varies (from 30V dc to 16V dc). Fitted with a PMMA diffusing filter and optics with plastic (methacrylate) lens for Wall Grazing lighting.

Direct linear luminaire with Warm White multi-LED, made of extruded aluminium with tempered glass screen and stainless-steel screws. It offers multiple installation options, high weather and UV resistance, IP66 connectors for pass-through wiring, and uses a Flood optic with Opti Beam Reflector. Power supply and control card (DMX/DALI) are sold separately.

Single emission projectors for outdoor application. The warm white LED light source with a spot light distribution is composed of 1 arrayled LEDs. The luminaire body is made of aisi 316 steel and features a steel finish, processed by means of electropolishing; the diffuser is made of extra clear glass - tempered with a silk-screening treatment. The ingress protection degree is IP68.IK10.

The versatile mounting types and luminaires of the IMAGINE family offer variable and professional lighting solutions for retail applications, hotels and restaurants. IMAGINE is flexibly configurable, technically sophisticated and can be perfectly integrated into any interior design. IMAGINE downlights are available as a round recessed version or as a round/square trimless downlight version.
