WAKO

double emission pendant luminaires for indoor application. The warm white LED light source with a diffused light distribution is composed of 64 topled LEDs with CCT of 3000 K and a CRI 80; the source luminous flux is 2414 lm, with a 150.9 lm/W nominal luminous efficacy. The device body is made of iron and features a embossed white ral 9003 finish, processed by means of coating; the diffuser is made of pmma; the mounting frame is made of iron, with a zinc finish, processed by means of washing. The ingress protection degree is IP20; the total weight is of 1.4 kg. The total absorbed power is 20 W. The device features protection class II and can be wall lights-mounted. Compliant with the EN 60598-1 standard and its specific provisions

Round recessed luminaire with contact frame. Fixed version. The LED is set back to minimize glare . The main body is made of diecast aluminium with a radiant surface that guarantees optimum heat dissipation. Metallised, thermoplastic, high definition reflector - medium optic. Structure with die-cast aluminium external contact frame with a single white finish. The internal ring is made of thermoplastic available in a range of painted and metallised finishes. Safety glass included Quick and easy tool free assembly. High color rendering index 3,000K LED. Power unit available with a separate code no.

LED source included. 24V dc remote electric power supply to be ordered separately. Includes a spring for plasterboard installations. The luminaire is equipped with a protruding, neoprene, 200 mm cable and a wiring kit with crimp connectors and adhesive heat-shrink tubing guaranteeing the water tightness of the connection. Transparent polycarbonate diffuser.
