ARISTO

LED DOT

OUTDOOR LIGHTING

PENTA WIDE IV CC-C APW4C-27H-C 1.2M

High performance wide angle light LED MODULE, design for low depth, narrow width lighting distribution system. DC24V constant voltage driven technology. Suitable for huge signage and ceiling light application. Easy to install and flexible, good for on-site installation. Come with 15 modules in one chain. Significant reduction in the quantity modules for larger lighting area. IP67

PANEL DIMENSION : 1200 MM (L)x600 MM (W)x 100 MM(D)

Specification

Power

LED 75.6W/PANEL

Color Temperature

2700K

Light Source Type

LED

Lumen Output

7920 LM/PANEL

Finishing

CLEAR

IP Rating

IP67

Color Rendering

CRI 80

Driver

ON/OFF DRIVER

LINEALIGHT

CEILING LIGHT

INDOOR LIGHTING

Single emission ceiling lights for indoor application. The warm white LED light source with a diffused light distribution is composed of 78 topled LEDs with CCT of 3000 K and a CRI 80; the source luminous flux is 8190 lm, with a 136.5 lm/W nominal luminous efficacy. The device body is made of aluminium 6060 and features a embossed white ral 9003 finish, processed by means of powder coating; the diffuser is made of pmma. The ingress protection degree is IP20; the total weight is of 11.32 kg. The device features protection class I and can be ceiling-mounted, with a 655 mm diameter hole (in plasterboard). Compliant with the EN 60598-1 standard and its specific provisions.

LINEALIGHT

WALLWASHER

OUTDOOR LIGHTING

Single emission lines for outdoor application. The super warm white LED light source with a elliptical light distribution is composed of 12 powerled LEDs . The luminaire body is made of aluminium 6060 and features a anodised aluminum finish, processed by means of 20 µm anodizing; the diffuser is made of extra clear glass - tempered with a silk-screening treatment. The ingress protection degree is IP68.IL08.

MEYER

SURFACE SPOTLIGHT

OUTDOOR LIGHTING

All exterior parts are stainless steel, tempered high efficiency safety glass, anti‐reflective coating from 1 side, silicon gasket, with 2 stainless steel screws, mounting bracket.Tilt range: 185°, highly efficient faceted rotationally symmetrical reflector, Constant current control (48 V DC), CRI 81, Beam angle (fwhm): 6°, luminous flux: 528 lm, wattage: 9 W, delivered lumens 59 lm/W, IP65,IK08,weight 0.8 kg
