LOUIS POULSEN

Passo step luminaire is a product that catch the attention and can amaze for its ability to generate shadows and reflections. With the version made in corten steel the shapes and the volume of the product are highlighted while with the version in frosted stainless steel, the colours of the surrounding environment are reflected, generating unexpected flashes. In its simplicity and purity, Passo can be installed in any type of environment, perfectly fitting into it. IP67, IK06

Single emission bollard & pole for outdoor application. The warm white LED light source with a asymmetric 180° light distribution is composed of 1 arrayled LEDs. The luminaire body is made of die-cast aluminium en ab - 46100 and features a grey finish, processed by means of open pore anodizing + powder coating; the diffuser is made of uv resistant polymethylmethacrylate. The ingress protection degree is IP65, IK09.

Single emission ceiling lights for outdoor application. The warm white LED light source with a medium flood light distribution is composed of 5 powerled LEDs with CCT of 3000K and a CRI 80; the source luminous flux is 2016 lm, with a 124.4 lm/W nominal luminous efficacy. The device body is made of aluminium 6060 and features a embossed black ral 9005 finish, processed by means of open pore anodizing + powder coating; the diffuser is made of uv resistant polycarbonate with a sandblasting treatment; the diffuser is made of extra clear glass - tempered with a sandblasting treatment. The ingress protection degree is IP67,IK08.

Single emission downlights for indoor application. The warm white LED light source is composed of 1 powerled LEDs. The device body is made of die-cast aluminium en ab - 46100 and features a embossed black ral 9005 finish, processed by means of powder coating; the diffuser is made of uv resistant polycarbonate. The ingress protection degree is IP44; the total weight is of 0.078 kg. The power supply driver is not provided and is to be ordered separately. The power supply cable is included and features a 0.170 m length. The device features protection class III and can be ceiling-mounted, with a 46 mm diameter hole (in plasterboard). Compliant with the EN 60598-1 standard and its specific provisions.
