XAL

24 V, IP67 protected and IK10 certified, linear LED luminaire for indoor and outdoor in-ground installation. Suitable for installation into roads and parking lots according to EN 60598-2-13. To be walked on and traversed by vehicles with air filled tires (including trucks used for delivery). Polyurethane encapsulation offering a premium water proof sealing (values), UV resistance (no coloration or increase of absorption) chemical stability against urban gazes and protection against abrasion. Stainless Steel V4A housing delivered with male/female IP67 connectors. Available either with an opal top layer or transluscent with an internal 10° and 30° lenses for wall grazing. Light source assembled using state of the art automated Reel-to-Reel (R2R) production process supporting LED Linear™ Tj Away thin flexible circuit board technology.

Luminaire made of aluminium alloy, aluminium and stainless steel BEGA Tricoat® coating technology Colour graphite or silver Safety glass with optical structure Required recessed opening 175 x 175mm Recessed depth 105mm Fixing is achieved by using two adjustable wedge-shaped claws.2 cable entries for through-wiring of mains supply cable ø 7-10.5mm, max. 5G1.5@ Connecting terminal and earth conductor terminal 2.5@ Complies with flicker requirements in accordance with IEEE 1789, DIN IEC/TR 63158, D

Single emission projectors for indoor application. The warm white LED light source with a flood light distribution is composed of 1 arrayled LEDs. The device body is made of die-cast aluminium en ab - 46100 and features a embossed black ral 9005 finish, processed by means of powder coating. The ingress protection degree is IP20; the total weight is of 0.920 kg. The device features protection class II and can be ceiling-mounted. Compliant with the EN 60598-1 standard and its specific provisions.
