UNILAMP

Single emission uplights for outdoor application. The warm white LED light source with a spot light distribution is composed of 1 arrayled LEDs. The luminaire body is made of aisi 316l steel and features a steel finish; the diffuser is made of extra clear glass with a silk-screening treatment. The ingress protection degree is IP68,IK08.

Beam Master 60 Zummy is an adjustable spotlight with adjustable light beam. By turning the ring it’s possible to keep the width of the light beam constant even if the lamp is placed at different ceiling heights. The ring is enriched with knurled engravings.

Surface luminaire housing from extruded aluminium profile, angular design, no visible screws, surface powder coated in white, grey or black. Luminaire profile with pre-assembled converter unit can be pre-mounted. light inset can be installed without tools. light inset made from extruded profile for improved thermal management. (reflector version). HPO (High Performance Opal) cover uniform illumination. or micro prismatic PMMAdiffuser include diffuser film for homogeneous illumination and reduced luminance. or with specially computedasymmetrical lens for homogeneous vertical lighti9ng intensity or high quality. chromed reflector with faceted design.IP20.

The luminaire housing made of die‑cast aluminum AlSi12, polyester powder coated by high‑quality and UV‑stabilized coating process, Colour: silver grey , all exterior parts are stainless steel, tempered safety glass, anti‑reflective coating from 1 side, dark screenprint, silicon gasket, closure with 4 stainless steel screws, mounting bracket powder coated aluminum: 2 drilled holes Ø 8.5 mm, spacing 50‑70 mm, 1 centre hole Ø 17 mm, tilt range: 205°,

cable gland: M20, connecting terminal: 3 pole, efficient highgloss aluminum reflector in combination with hybrid lens fornarrow beam light distribution in shallow luminaire housing, DIMENSIONS: 280*75*280mm.
